Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)

Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)

    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
    • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)
  • Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)

    Product Details:

    Place of Origin: CHINA
    Brand Name: POETRONICS
    Certification: CE, RoHS, FCC
    Model Number: POE-S0008GE

    Payment & Shipping Terms:

    Minimum Order Quantity: 50units
    Packaging Details: Carton Box
    Delivery Time: 1-30days
    Payment Terms: T/T, Western Union, Paypal, L/C, etc.
    Supply Ability: 9580
    Contact Now
    Detailed Product Description
    Switch Capacity: 52Gbps Ports: 8 Gigabit PoE
    Ethernet Protocol: IEEE802.3af/at Flow Control: Full-duplex: IEEE 802.3x; Half-duplex: Back Pressure
    Power Input: AC100-240V, 50~60Hz Power Output: DC48~57V, 120W
    PoE Power: Max. 30W Every Single Port PoE Current: Max. 625mA Every Single Port
    Function: PoE-Power Over Ethernet Product Status: Make-to-Order

    POE-S0008GE (8 GE POE, 120W External power supply, 52G bandwidth, IEEE802.3af/at)

    Overview
    POE-S0008GE is an unmanaged PoE Switch that comes with 8 ports 10/100/1000Mbps (Gigabit) PoE, any one of these 8 ports can be used as uplink. It is IEEE802.3af/at compliant, equipped with 120W external regulated power supply source or driven by external DC48-57V power supply.

    POE-S0008GE is widely working with 7 units of Powered Device (PD) such as security IP camera, VoIP phone, wireless AP/Routers or other compatible powered device, the 8th port is specially used as uplink and any of these ports power output is max. 30W.


    Key Features
    ◆ 8 10/100/1000Mbps ports PoE
    ◆ AC100-240V, 50/60Hz or DC 48~57V two different input modes for optional
    ◆ Compliance with IEEE802.3af/at, support full ports advance standard detection
    ◆ Flow control: Full-duplex: IEEE 802.3x; Half-duplex: back pressure
    ◆ Support Auto MDI/MDIX, Store-and-forward switching, 52G bandwidth
    ◆ Max 30W for every single port, total rated output power 120W
    ◆ Support wire speed switching and jumbo frame transmission for all ports
    ◆ Plug and play, self-adaption, second-level lightning protection
    ◆ PoE working status can be read and analyzed through LED indicators on front panel
    ◆ Applied to CCTV IP camera, wireless AP, VoIP phone and other device requiring power over Ethernet cable

    Specification

    ModelPOE-S0008GE
    Ports8 10/100/1000Mbps POE
    Power InputAC 100-240V, 50/60Hz, 1.0A
    Power OutputDC 48-57V, 120W(Rated, ), Max. 30W for every single port
    Data Exchange10/100Mbps, Store and Forward
    Bandwidth/MAC2G, 1K
    Power/Data AssignmentPower: pin 1,2 “+”, pin 3,6 ”-”; Data: pin 1,2,3,6
    Ambient Environment

    Operating temperature: 0~40℃

    Storing temperature: -40~70℃
    Operating Humidity: 10%~90% RH, No condensing
    Storing Humidity: 5%~90% RH, No condensing
    Network Protocol

    IEEE 802.3 Ethernet media access control protocol

    IEEE 802.3i 10BASE-T Ethernet

    IEEE 802.3u 100BASE-TX Fast Ethernet

    IEEE 802.3ab 1000BASE-TX Gigabit Ethernet

    IEEE 802.3af/at Power over Ethernet cable pairs or device

    IEEE 802.3x Flow control

    Data Speed

    Ethernet 10Mbps half-duplex, 20Mbps full-duplex

    Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex

    Gigabit Ethernet 2000Mbps full-duplex

    Network Medium

    10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m)

    100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m)

    1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(≤150m)

    Safety/CertificateCE, FCC, RoHS
    Warranty1 Year (Implied)
    Size/Weight

    PoE Size: 225*105*32mm (L*W*H)
    Box Size: 300*175*100mm (L*W*H)
    Net Weight: 1.3kg, Gross Weight: 1.45kg




    Application Diagram
    Latest POE-S0008GE(52G) 8 Port Gigabit IEEE802.3af/at PoE Switch (120W External Power Source)

    Item8 Port Gigabit (10/100/1000Mbps) Unmanaged Power over Ethernet Switch
    ModelPOE-S0008GE
    Interface8 GE PoE RJ45 Ports
    Power InputAC100-240V, 50/60Hz
    Power OutputDC 52V, 2.2A, 120W external power supply, Max 30W for every single port
    Data Exchange10/100/1000Mbps, Store and Forward switching
    Power/Data AssignmentPower: pin 1,2/4,5 “+”, 3,6/7,8 “-”; Data: pin 1,2,3,6
    Bandwidth/MAC52Gbps, 4K
    Ambient EnvironmentOperating temperature: 0~50℃
    Storing temperature: -40~70℃
    Operating Humidity: 10%~90% RH, No condensing
    Storing Humidity: 5%~90% RH, No condensing
    Standards Protocols

    IEEE 802.3
    IEEE 802.3i 10BASE-T
    IEEE 802.3u 100BASE-TX
    IEEE 802.3ab 1000BASE-T
    IEEE 802.3af/at
    IEEE 802.3x

    Data Speed

    Ethernet 10Mbps half-duplex, 20Mbps full-duplex
    Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex
    Gigabit Ethernet 2000Mbps full-duplex

    Network Media

    10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m)
    100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m)
    1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(≤150m)

    Safety ApprovedCE, FCC, ROHS
    Warranty1-3 years
    Product specifications

    PoE Size: 225*105*32mm (L*W*H)
    Box Size: 300*175*100mm (L*W*H)
    Net Weight: 1.3kg, Gross Weight: 1.45kg

    Packaging Accessory

    1x User Manual
    1x AC Cable
    2x Mounting Racks
    7x Philip's head screws
















































    Application Diagram
